Comparative Properties of High Temperature Resins

RTP
Series
Polymer Morphology Glass
Transition
Temperature
°F (°C)
Continuous
Use
Temperature
°F (°C)
HeatDeflection
Temperature
w/ 40% glass fiber
@ 264 psi (1.82 MPa)
°F (°C)
1300 Polyphenylene Sulfide PPS SC 198
(92)
400-450
(204-232)
500
(260)
2200 Polyetheretherktone PEEK SC 290
(143)
450-500
(232-260)
600
(316)
2200 A Polyetherketone PEK SC 329
(165)
500-550
(260-288)
>600
(>316)
4000 Polyphthalamide PPA SC 257
(125)
350-400
(177-204)
535
(279)
4000 A Hot Water Moldable
Polyphthalamide
PPA SC 194
(90)
300-350
(149-177)
535
(279)
4100 Polyetherketoneketone PEKK SC 330
(166)
450-500
(232-260)
>600
(>316)
4200 Polyimide TPI SC 482
(250)
500-550
(260-288)
630
(332)
4400 High Temperature Nylon HTN SC 257
(125)
300-350
(149-177)
500
(260)
900 Polysulfone PSU A 374
(190)
300-340
(149-171)
365
(185)
1400 Polyethersulfone PES A 435
(224)
350-400
(177-204)
420
(216)
2100 Polyetherimide PEI A 415
(213)
350-400
(177-204)
410
(210)
3400 Liquid Crystal Polymer LCP LC 400-500
(204-232)
610
(321)



Definitions

  • Glass Transition Temperature (Tg) — Temperature at which a material goes from a glassy state to a rubbery state. Key property changes include softening, reduction in density, and large drop in strength and modulus.
  • Continuous Use Temperature — Function of the thermal breakdown of the polymer. Difficult to increase by adjusting additives.
  • Heat Deflection Temperature — Temperature at which a material will deflect a specified amount at a specified load. Good indicator of short term/low load thermal capabilities.
